Sanitation Enterprise Sewage Suction Truck 8-12CBM LHD 4X2 , Liquid Waste Trucks

Sanitation Enterprise Sewage Suction Truck 8-12CBM LHD 4X2 , Liquid Waste Trucks

  • Sanitation Enterprise Sewage Suction Truck 8-12CBM LHD 4X2 , Liquid Waste Trucks
  • Sanitation Enterprise Sewage Suction Truck 8-12CBM LHD 4X2 , Liquid Waste Trucks
  • Sanitation Enterprise Sewage Suction Truck 8-12CBM LHD 4X2 , Liquid Waste Trucks
  • Sanitation Enterprise Sewage Suction Truck 8-12CBM LHD 4X2 , Liquid Waste Trucks
Sanitation Enterprise Sewage Suction Truck 8-12CBM LHD 4X2 , Liquid Waste Trucks
Ürün ayrıntıları:
Place of Origin: China
Marka adı: SINOTRUK HOWO
Sertifika: ISO/3C/BV/IFA/SGS
Model Number: ZZ1167M4611W
Ödeme & teslimat koşulları:
Minimum Order Quantity: 1 Unit
Fiyat: USD45800-USD46000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
İletişim
Detaylı ürün tanımı
Ürün adı: Kanalizasyon Emme Kamyonu modeli: ZZ1167M4611W
sürücü tipi: LHD 4x2 emisyon standardı: Avro 2
Motor: WD615.62, 266HP Tank Gövde Kapasitesi: 8-12CBM
Vurgulamak:

kanalizasyon pompası kamyonu

,

septik tank pompası kamyonu

,

Sanitasyon Kurumsal Kanalizasyon Emme Kamyonu

Sewage Suction Truck SINOTRUK HOWO for Sanitation Enterprise 8-12CBM LHD 4X2



Description:



Sewage Suction Truck SINOTRUK HOWO for Sanitation Enterprise 8-12CBM LHD 4X2

The introduction of Germany advanced manufacturing technology, with rising underground

sewage pipes,the collection and transportation of sludge, city life waste and building

operations such as muddy water  in liquid waste and other functions.



Suction sewage truck is sanitation vehicles which is used for collecting and transporting

sewage and  sludge in municipal, enviromental sanitation and large property managerment

company ,to avoid  secondary pollution ,with vacuum suction ,pressure discharge function

efficient and time saving vacuum pump,valve and others are imported products.



Which can choose all kinds of Brand, Such as HOWO, Golden Prince, HOWO A7, Hohan, Engine

power have 266HP, 290HP, 336HP, 371HP and so on.





Specification:



Sewage Suction Truck SINOTRUK HOWO for Sanitation Enterprise 8-12CBM LHD 4X2

Chassis Model

ZZ1167M4611W

Drive Type

4×2

Engine

WD615.62, 266HP

Cabin

HW76 lengthened cab(with one sleeper, air-conditioner and two new-style seat)

Transmission

HW15710(10 forwards & 2 reverses)

Front Axle

HF7 (1X7Tons)

Driving Axle

HC16(1X16Tons)

Clutch

hydraulically operating with air assistance

Rim/ Tire

11.00R20

Wheel base

4600(mm)

Capacity of tank body

8-12CBM

Diameter of suction tube

Φ100mm

Suction depth

≥ 8 m

Vacuum pump

type: Vane pump

Pumping speed: 318 m3/h

Rated speed: 1300rpm

Overall dimension

7128×2462×3175mm

The curb weight

8010(Kg)

Gross weight

16000 kg

Max. speed

95km/h

Color

White, red, green, golden and so on.


Applications:



Can be widely used in the collection of urban rain wells, inspection wells and all kinds of ditches within

the sludge, sewage or oil chemical sewage tank sediment suction, shipment and discharge.



Competitive Advantage:



1) Including chassis, power takeoff, transmission shaft, vacuum suction pump, pressure

tank, hydraulic parts, pipe system, vacuum pressure gauge, waste composition window,

washing device, vehicle configuration for high power vacuum suction pump and the quality

of the hydraulic system, the tank head once pressed, the tank rear door can open and dump

by two cylinder.
2) Our company produces the truck has the function of opening rear door by hydraulic

system, the opening angle of 60 degrees. The hand wheel lock, also optional automatic

hydraulic lock. The special seal, tightness is high reliability. The arrangement of

vacuum pump is more flexible, in accordance with the optimization of the vacuum pipeline

installation, but also for the hydraulic drive the automatic control system brings

convenience.
3) The optimized hydraulic control system helps to avoid wrong operation, it has higher

safety and running efficiency.
4) excellent appearance of cabin, safety, reliable
5) low fuel consumption
6) with all kinds of truck model, which can fulfill your requirement
7) the key parts adopt the world's top technology products
8) based on strong technical support and top level technology make the trucks with high

quality and more reliable
9) competitive price, cost-effective
10) quick and efficient spare parts supply bring you more convenient
11) fast delivery time, we can arrange production according to your needs exactly and

quickly
12) professional import and export dealing procedure, make customs clearance more high

efficiency
