SINOTRUK HOKA Concrete Mixer Truck Euro2 290HP 6X4 ZZ5255GJBM3846B1

SINOTRUK HOKA Concrete Mixer Truck Euro2 290HP 6X4 ZZ5255GJBM3846B1

  • SINOTRUK HOKA Concrete Mixer Truck Euro2 290HP 6X4 ZZ5255GJBM3846B1
  • SINOTRUK HOKA Concrete Mixer Truck Euro2 290HP 6X4 ZZ5255GJBM3846B1
  • SINOTRUK HOKA Concrete Mixer Truck Euro2 290HP 6X4 ZZ5255GJBM3846B1
  • SINOTRUK HOKA Concrete Mixer Truck Euro2 290HP 6X4 ZZ5255GJBM3846B1
SINOTRUK HOKA Concrete Mixer Truck Euro2 290HP 6X4 ZZ5255GJBM3846B1
Ürün ayrıntıları:
Place of Origin: China
Marka adı: SINOTRUK HOKA
Sertifika: ISO/3C/BV/IFA/SGS
Model Number: ZZ5255GJBM3846B1
Ödeme & teslimat koşulları:
Minimum Order Quantity: 1 Unit
Fiyat: USD49500-USD50000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
İletişim
Detaylı ürün tanımı
Ürün adı: beton karıştırıcı kamyon modeli: ZZ5255GJBM3846B1
sürücü tipi: LHD 6X4 emisyon standardı: Avro 2
Motor: WD615.87, 290HP Tank Gövde Kapasitesi: 10 metreküp
Vurgulamak:

Kamyona monte beton mikseri

,

Mobil beton mikseri Kamyonu

,

SINOTRUK HOKA Beton Mikseri Kamyonu

SINOTRUK HOKA Concrete Mixer Truck 10CBM Euro2 290HP 6X4 LHD ZZ5255GJBM3846B1



Description:



The Concrete Mixer Truck series of products produced by adopt Germany's proprietary technology.

The hydraulic sytem adopts abroad techology and key parts imported from America, Italy, German and

so on.



This products use the imported reducer, motor and hydraulic pump. Dynamic force output by the

second class chassis full power take off through the shaft power to the hydraulic pump, hydraulic pump

produces hydraulic energy through tubing to the hydraulic motor, hydraulic motor to convert hydraulic

energy into kinetic energy and through reducer then reduce and increase twist to the mixing tank, by

adjusting the (double acting variable) servo controller of hydraulic pump Angle so as to realize

controlling turning and speed of mixing drum, then to realize the concrete charging, stir and discharging

operation.



Specification:



SINOTRUK HOKA Concrete Mixer Truck 10CBM Euro2 290HP 6X4 LHD ZZ5255GJBM3846B1

Model ZZ5255GJBM3846B1
Drive Type 6×4
Engine

WD615.87 , 290HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin H16 lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8098 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3825+1350(mm)
Overall dimension 9090×2496×3950(mm)
Tank body Capacity

10CBM

The curb weight 13010(Kg)
Gross weight 25000 kg
Max. speed 102km/h
Color White, red, green, golden and so on.




Applications:



t’s suitable for agitating and transiting concrete, for construction site, road repairing and some other

infrastructure construction business.



Competitive Advantage:



1) based on strong technical support and top level technology make the trucks with high

quality and more reliable
2) competive price, cost-effective
3) quick and efficient spare parts supply bring you more convenient
4) fast delivery time, we can arange production according to your needs exactly and

quickly

5) professional import and export dealing precedure, make customs clearance more high efficiency

6) The leading product technology, complete function, excellent performance, reliable quality, easy to

   operate.

7) Optimization of body structure, special mold production, beautiful appearance, concrete mixing,

    discharge uniformity, low rate of residual.

8) Imported hydraulic pump, hydraulic motor and speed reducer.

9) Uses the high strength steel plate, long service life.

10) Optimization of the whole structure, low center of gravity, high running efficiency.

11)Product range is wide, the tank capacity of 6 to 18 cubic meters.

12) Choose a variety of auxiliary device.

13) Match all concrete mixer truck chassis.
